Vivotek IT9388-HT 5MP H.265 IR Outdoor Turret IP Security Camera with Varifocal Lens

System Information

Model

IT9388-HT

CPU

Multimedia SoC (System-on-Chip)

Flash

128MB

RAM

512MB

Camera Features

Image Sensor

1/2.7″ Progressive CMOS

Max. Resolution

2560×1920 (5MP)

Lens Type

Vari-focal, Remote Focus

Focal Length

f = 2.8~ 12 mm

Aperture

F1.4 ~ F2.8

Auto-iris

Fixed-iris

Field of View

30° ~ 88° (Horizontal)
23° ~ 65° (Vertical)
38° ~ 115° (Diagonal)

Shutter Time

1/5 sec. to 1/32,000 sec.

WDR Technology

WDR Pro

Day/Night

Yes

Removable IR-cut Filter

Yes

IR Illuminators

Built-in IR illuminators, effective up to 30 meters with Smart IR, IR LED*2

Minimum Illumination

0.035 Lux @ F1.4 (Color)
<0.005 Lux @ F1.4 (B/W)
0 Lux with IR illumination on

Pan Range

360°

Tilt Range

70°

Rotation Range

360°

Pan/Tilt/Zoom Functionalities

ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)

On-board Storage

Slot type: MicroSD/SDHC/SDXC card slot
Seamless Recording

Video

Video Compression

H.265, H.264, MJPEG

Maximum Frame Rate

20 fps @ 2560×1920

Maximum Streams

3 simultaneous streams

S/N Ratio

61 dB

Dynamic Range

120 dB

Video Streaming

Adjustable resolution, quality and bit rate control, Smart Stream III

Image Settings

Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks; Scheduled profile settings, HLC, defog, 3DNR, video rotation

Audio

Audio Capability

One-way Audio

Audio Compression

G.711, G.726

Audio Interface

Built-in microphone

Effective Range

5 meters

Network

Users

Live viewing for up to 10 clients

Protocols

802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP

Interface

10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.

ONVIF

Supported, specification available at www.onvif.org

Solution Integration

Video Motion Detection

Five-window video motion detection

VADP Package

Trend Micro IoT Security, Stratocast

Alarm and Event

Alarm Triggers

Motion detection, periodical trigger, system boot, recording notification, camera tampering detection, audio detection, manual trigger, SD card life expectancy, cybersecurity events (brute force attack event, cyberattack event, quarantine event)

Alarm Events

Event notification via email, HTTP, FTP, NAS server, SD card
File upload via email, HTTP, FTP, NAS server, SD card

General

Connectors

RJ-45 cable connector for 10/100Mbps Network/PoE connection*1

LED Indicator

System power and status indicator

Power Input

IEEE 802.3af PoE Class 0

Power Consumption

Max. 9.8 W (IR on)
Max. 6.29 W (IR off)

Dimensions

Ø 120 x 90.5 mm

Weight

625 g

Casing

IP66, IK10(Metal Housing)

Safety Certifications

CE, FCC Class B, UL, LVD, VCCI, C-Tick

Operating Temperature

Starting Temperature: -10°C ~ 60°C (14°F ~ 140°F)
Working Temperature: -30°C ~ 60°C (-22°F ~ 140°F)

Humidity

90%

Warranty

24 Months

System Requirements

Operating System

Microsoft Windows 8/7
Mac 10.12 (Chrome only)

Web Browser

Chrome 58.0 or above
Internet Explorer 10/11

Other Players

VLC: 1.1.11 or above
QuickTime: 7 or above

Included Accessories

Others

Quick installation guide, alignment sticker, screw pack, cable gland
